BR301-NP Digital Fiber Amplifier (Product End-of-Life Notice)
• Offer 1-point/2-point setting, high/low power output selectable, easy to mistable setting, easy to install.
• Depends on the mounting direction, the digital display of BR3 can be inverted.
• Response time selectable:(200、500、1000、5000)μs.
Description
Specification
| Emitting light | RED LED 660nm |
|---|---|
| Operating voltage | DC 12 to 24 ±10% |
| Current consumption | 45mA Max. |
| Load current | 100mA Max. at DC 24V |
| Model / Type | NPN L.on / D.on |
| Protection circuit | Reversed polarity, over-current protection |
| Response time / | on : 200 μs, off: 200 μs MAX (200、500、1000、5000)μs |
| Indictors | Output indicator : Red LED |
| Sensitivity adjustment | 4 Digits 0000-8000 |
| Insulation resistance | 20 MΩ min. (DC500V) |
| Voltage withstandability | AC500V 60Hz for 60 Sec. |
| Opera tetemperature | - 10 ℃ ~ + 60 ℃ |
| Operating temperature | 35% ~ 85% RH |
| Protection degree | IP50 |
| Casing material | ABS |
| Wiring method | Pre-wired Ø4.2 x 2 M / 3-wires |
| Weight | Approx. 65 g |
